• Features

Límites de operación:
Presión: ≤1.2MPa
Velocidad: ≤10m/s
Temperatura: -20℃~+90℃

● Anillo giratorio (SiC/TC/Carbono)
● Anillo estacionario (SiC/TC/Cerámica)
● Sello secundario (VITÓN/Anillo encapsulado/PTFE/NBR/EPDM)
● Otras piezas (SUS304/SUS316/ Titanio/Hastelloy-C)

d (mm)	d2	d3		d9	da	l1	l2	l3	l4	T
		min	max
25	38.4	41.5	51.0	60	105	65.5	41.0	24.5	23	1/4NPT
28	42.4	44.5	52.0	60	105	68.0	41.5	26.5	23	1/4NPT
30	42.4	45.5	56.0	63	105	68.0	41.5	26.5	23	1/4NPT
33	45.0	48.0	57.0	65	110	69.5	42.0	27.5	23	1/4NPT
35	49.1	50.8	61.5	68	107	72.5	44.0	28.5	26	1/4NPT
38	51.3	54.5	66.0	73	123	72.5	44.0	28.5	26	1/4NPT
40	54.3	57.5	68.0	75	123	75.5	44.5	31.0	26	1/4NPT
43	56.3	59.5	70.5	78	133	76.5	44.5	32.0	26	1/4NPT
45	59.8	63.0	73.0	79	130	76.5	44.5	32.0	26	1/4NPT
48	61.8	65.0	75.0	82	130	78.0	45.0	33.0	26	1/4NPT
50	64.8	68.0	78.0	85	148	80.5	47.0	33.5	28	3/8NPT
53	66.8	70.0	87.0	95	148	81.5	47.0	34.5	28	3/8NPT
55	71.0	73.0	83.0	90	148	83.5	47.0	36.5	28	3/8NPT
60	76.5	79.0	91.0	100	157	85.5	47.0	38.5	28	3/8NPT
65	83.0	85.7	98.5	108	162	88.0	48.5	39.5	28	3/8NPT
70	88.0	94.0	108.0	116	178	92.0	48.5	43.5	28	3/8NPT
75	93.4	98.4	118.0	125	190	93.5	49.0	44.5	28	3/8NPT
